PMI GROUP was established in 1990. It’s highly involved in manufacturing of ballscrews, which is the critical component of precision machinery and mainly applied to Machine Tool, Electric Discharging Machine, Cutting Wire Machine, Plastics Injection Machine, Semi-conductor Equipment, Precision Orientation ...

High positioning accuracy,
high repeatability

The PMI linear guideway is a design of rolling motion with a low friction coeffi cient, and the diff erence between dynamic and static friction is very small. Therefore, the stick-slip will not occur when submicron feeding is making.

Low frictional resistance,
high precision maintained
for long period

The frictional resistance of a linear guideway is only 1/20th to 1/40th of that in
a slide guide. With a linear guideway, a well lubrication can be easily achieved by supplying grease through the grease nipple on carriage or utilizing a centralized oil pumping system, thus the frictional resistance is decreased and the accuracy could be maintained for long period.

High rigidity with
four-way load design

The optimum design of geometric mechanics makes the linear guideway to bear the load in all four directions, radial, reversed radial, and two lateral directions. Furthermore, the rigidity of linear guideway could be easily achieved by preloading carriage and by adding the number of carriages.

Suitable for high speed
operation

Due to the characteristic of low frictional resistance, the required driving force is much lower than in other systems, thus the power consumption is small. Moreover, the temperature rising effect is small even under high speed operation.

Easy installation with
interchangeability

Compared with the high-skill required scrapping process of conventional slide guide, the linear guideway can offer high precision even if the mounting surface is machined by milling or grinding. Moreover the interchangeability of linear
guideway gives a convenience for installation and future maintenance.

The trains of balls are designed to a contact angle of 45° which enables it to bear an equal load in radial, reversed radial and lateral directions. Therefore, it can be applied in any installation direction. Furthermore, MSA series can achieve a well balanced preload for increasing rigidity in four directions while keeping a low frictional resistance. This is especially suit to high precision and high rigidity required motion.
The patent design of lubrication route makes the lubricant evenly distribute in each circulation loop. Therefore, the optimum lubrication can be achieved in any installation direction, and this promotes the performance in running accuracy, service life, and reliability.

Characteristics

‧High Rigidity, Four-way Equal Load

‧Self Alignment Capability

‧Smooth Movement with Low Noise

‧Interchangeability

Dimension (clickable)

MSA-A/MSA-LA、MSA-E/MSA-LE、MSA-S/MSA-LS

CAD file download (clickable)

MSA CAD file download

Carriage Type

Rail Type

Description of Specifi cation

Accuracy Grade

Preload Grade

The Shoulder Height and Corner Radius for Installation

Dimensional Tolerance of Mounting Surface

Rail Maximum Length and Standrad

Tapped-hole Rail Dimensions

MSA A/LA	×Close Window

Note: Request for size 55 and 65 MSA-A / MSA-LA carriage, please refer to MSA-E / MSA-LE carriage type.
Note: The basic dynamic load rating C of ball type is based on the 50 km for nomonal life.
　　　The conversion between C for 50 km and C₁₀₀ for 100 km is C=1.26 x C₁₀₀.
Note*: Single: Single carriage/ Double: Double carriages closely contacting with each other.
